Digitally driven advanced manufacturing processes achieve high-quality production and delivery of complete machines. Revitalize the experience, making boxes has become efficient and easy since then.
Product Details
| Specification | |
|
|
| Function | Single side gluing +double sides gluing+lock bottom |
| Paper board | 210-800 g/m², N/E/F corrugated box |
| Speed | 0-300 m/min |
| Power | 15KW 380V 3P |
| Weight | 5000KG |
| Package | 5 packages with wooden cases |
| Delivery Time | 7-21 days |
| MOQ | 1 set |
| Loading port | NINGBO PORT, CHINA |
| Payment | by TT/ LC/ Western Union |
| Shipping way |
By sea/ truck/ train/ courier |
| Model | ZH-1100YF | |||
| Box Type | Side gluing Box | Lock Bottom Box | ||
| A Max | (mm) | 1100 | 1100 | |
| A Min | (mm) | 160 | 200 | |
| B Max | (mm) | 800 | 800 | |
| B Min | (mm) | 65 | 65 | |
| C Max | (mm) | 530 | 530 | |
| C Min | (mm) | 80 | 90 | |
| D Min | (mm) | 12 | 70 | |
| E Min | (mm) | 10 | 10 | |
FAQ
1.Q:What is the machine warranty?
A: 12 months
2.Q:Does your machine with CE certificate?
A:Yes, issued by Italian organization
3.Q:What is the production time while placing order?
A: 7-30 days, some model has in stock.
4.Q:What can be offered after paying deposit?
A: processing video and picture; Oversea technical guidance; installation videos. Oversea technician.
5.Q:Can your company handle shipping for customers?
A:Of course, just give us destination sea port or container yard
6.Q:Does the packing strong?
A:Yes, all packages are double-checking before delivery
7.Q:How about after-sales service process?
A: We offer life time A.S.S. Please feel free to contact after-sales department.
8.Q:Are you manufacturer or trading company?
A: We are manufacturer. We have qualification for exporting goods.
9.Q:Do you have machines in stock?
A: For standard model, we have a large quantity in stock. For special model,
we need 20-30 days to produce it.
10.Q:Do you inspect machines before packing?
A:Of course we do.we have QC department to debug the machine before packing
11.Q:What’s the payment term?
A: T/T 30% in advance, the balance paid before delivery.
We also accept payment via West Union and L/C.
12.Q: Do you accept factory visiting?
A: We are highly greeting for your visiting.
